CANNONDALE SCALPEL 3 (MEDIUM)

Frame Size: Medium

Highlights

Superlight Carbon frame with FlexPivot, 120mm travel, and Proportional Response-Tuned Suspension and Geometry

Lightweight RockShox SID Select 120mm fork and SIDLuxe Select+ rear shock

Shimano’s legendary XT 12-speed shifting

Powerful, controllable Shimano Deore M6100 hydraulic disc brakes

Stan’s tubeless-ready Crest Mk4 rims with Maxxis Rekon Race and Aspen WT 2.4” tires

Cannondale’s DownLow dropper seatpost

Specs Details

Platform

Scalpel

Model Name

Scalpel 3

Model Code

C24454U

Frameset

Frame

Scalpel, lightweight carbon construction, 120mm travel, Proportional Response Suspension and Geometry, FlexPivot Chainstay, full internal cable routing, 73mm BSA, 1.5“ headtube with 1-1/8” upper reducer/internal cable guide, 148x12mm thru axle, 55mm chainline, UDH, post-mount disc – 160mm native

Fork

RockShox SID Select, 120mm, Debonair, 15x110mm thru-axle, tapered steerer, 44mm offset

Headset

Acros ICR

Rear Shock

RockShox SIDLuxe Select+, 2-Pos mode adjust, adjustable rebound, 190x45

Drivetrain

Rear Derailleur

Shimano XT

Shifters

Shimano XT, 12-speed

Chain

Shimano SLX M7100, 12-speed

Crank

Shimano Deore M6120, 32T

Rear Cogs

Shimano XT, 10-51, 12-speed

Bottom Bracket

Shimano BSA 73mm

Brakes

Brakes

Shimano Deore M6100, 180/160mm RT54 rotors

Brake Levers

Shimano Deore M6100

Wheels

Rims

Stan's NoTubes Crest MK4, 28h, tubeless ready

Spokes

DT Swiss Competition Race

Tire Size

2.4

Wheel Size

29

Hubs

(F) Shimano TC-500, 15x110mm thru-axle / (R) Shimano TC-500, 12x148mm thru-axle

Tires

(F) Maxxis Rekon Race WT, 29x2.4“, EXO Protection, tubeless ready / (R) Maxxis Aspen WT, 29x2.4”, EXO Protection, tubeless ready

Components

Handlebar

Cannondale 2 Flat, butted 2014 Alloy, 31.8mm, 3° rise, 8° sweep, 760mm

Stem

Cannondale C1 Conceal, Alloy, 31.8, -6°

Grips

Cannondale XC Silicone

Saddle

Prologo Dimension NDR, STN rails

Seatpost

Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M-XL)

Connectivity

Wheel Sensor

Cannondale Wheel Sensor

Please note that, based on component availability and other factors, specifications are subject to change without notice.
