Description

frame BIG.NINE TFS III material: aluminum 29x2.25“ max. wheelsize 135x9mm axle standard BSA bottom bracket standard color MATT BRONZE (BLACK) fork Rock Shox Judy TK Coil 100mm suspension travel Lockout 46mm fork offset 29x2.25” max. wheelsize brakes Power DS100 2 piston hydraulic disc brake rotors Shimano RT10 160 mm headset MERIDA M2345 handlebar MERIDA CC material: aluminium 690mm width 15mm rise handlebar stem MERIDA CC material: aluminium 31.8mm diameter 6° stem angle 70 mm-S, 80 mm-M, 90 mm-L, 100 mm-XL, 110 mm-XXL grip MERIDA EC derailleur (f) Shimano FD-M2000 derailleur (r) Shimano RD-M370 shifters Shimano seat post MERIDA CC material: aluminium 30.9mm diameter 15mm setback seat clamp MERIDA COMP QR saddle MERIDA SPORT COMFORT pedal VP VPE-891 chain KMC M99 crank Shimano MT101 40-30-22 teeth 170 mm-S, 175 mm-M/XXL Cassette Shimano CS-HG200 11-32 teeth 9 speed bottom bracket Shimano BB-UN100 hubs Shimano TX505 100x9mm width front hub 32 spoke holes Centerlock 135x9mm width rear hub 32 spoke holes Centerlock rim MERIDA CC 17mm inner width material: aluminium tyre front MERIDA K1080 29x2.2“ wire tyre rear MERIDA K1080 29x2.2” wire spokes Black steel max. weight 135 kg
